Think of how you’d feel if you packed your regular 110V U.S. coffee-maker to take with you on vacation, only to find all of the outlets at your destination in Europe are rated for 220V, which means if you simply plugged your coffee maker into the outlet it would fry the appliance… That is where a step-up transformer comes in to safely change the power supplied by the outlet to match the requirements of your appliance. While this example is a common use of a step-up transformer, they are also used frequently for many of the same reasons to run heavier-duty industrial equipment, commercial equipment, or when performing home renovations. This article will provide an overview of how a step-up transformer operates, examples of how they can be used, and helpful tips on how to select one that meets your needs.
How does a step-up transformer work?
A step-up transformer works on the principle of electromagnetic induction by converting a lower-level voltage input to an output of a higher-level voltage. A step-up transformer is made up of two coils of insulated copper (the primary and secondary) that are wrapped around a steel core. When you connect the primary coil of a step-up transformer to an alternating current (AC) voltage source, the electrical current flowing through the primary coil generates a constantly changing magnetic field within the core of the transformer (the steel core). Due to this constantly changing magnetic field, a voltage is produced in the secondary coil of the transformer. Because the secondary coil has more turns of insulated copper wire than the primary coil, the voltage produced in the secondary coil is at a higher level than what was supplied to the primary coil.
A good example of how a step-up transformer works is when there is a 110V to 220V step-up transformer. The secondary coil of this transformer will have two times as many turns of copper wire as the primary, and when connected to a 110V source, the transformer will supply a 220V output to an appliance. As a result, the appliance can operate safely in an area where there is a larger voltage level in the electric power grid. To summarize, the rule that governs how a Step Up Transformer works is simply stated: The ratio of the secondary turns to the primary turns will be equal to the ratio of the output voltage to the input voltage. Therefore, if you want to convert power from one source to another (input voltage) with as little waste as possible (efficiently), then follow this principle.
Step Up Transformer Applications
Step Up Transformers are used in almost every type of industrial application and are found being used in many different types of locations. The following are some of the most common ways that step-up transformers are used:
Home & Travel: Small Step Up Transformers
People who travel frequently or are living outside their home country usually want to take their appliances or electrical equipment with them. If your Country uses 110V or 100V electricity (like many countries in the Americas), and you are traveling to Europe where the electrical system operates on 220V or 240V; you will need a small transformer to convert the higher European voltage to the lower Canadian/American voltage. Small step up transformers range in physical sizes from about 500W to 3000W and can be used for powering small appliances such as hairdryers, computers or kitchen gadgets. For instance, if you purchase a 100V to 220V step up transformer, you will be able to use Japanese electrical products in Europe, and if you have a transformer that is rated at 110V to 220V you will be able to use your American electric products in Asia or Australia. Be sure to purchase a lightweight and portable transformer that has built-in surge protection to prevent your devices from being damaged.
Commercial Applications: Medium Power Step Up Transformers
Commercial business applications include using medium power step up transformers by restaurants, retail stores and offices to power equipment that was manufactured to use lower voltage. For example, a 3000W step up transformer can power a commercial pizza oven that was sold through a U.S. distributor, but will be used in a European kitchen. A 5000W step up transformer can operate a commercial/industrial size HVAC system. All of the medium-powered commercial transformers will typically have features such as overcurrent protection devices and will have heavy-duty metal housings so that they can be used continuously each day without breaking down.
Industrial Applications: 3 Phase Step Up Transformers
Industrial manufacturers perform their manufacturing operations with 3 phase step up transformers to operate their electric equipment used for manufacturing purposes. For example, the electric motors that operate large machines such as conveyors and pumping systems. High-capacity transformers (10KVA and greater) provide voltage increases — the proper voltage for running industrial equipment such as lights and motors. For instance, many factories use 3-phase Transformers to increase the standard of 240V to 480V for an electric motor to run the machine components of a large manufacturing line. Industrial type Transformers are manufactured to meet rigorous specifications established by their corresponding National Electrical Code (NEC) and under the direction of UL, CE, or other groups that address and verify the safety of these products and their installation.
Key Features When Purchasing a Step Up Transformer
When purchasing a step-up transformer, it you must consider the requirements and usage of the device or electrical components that you plan on utilizing the transformer with. Some of the main things consideration include:
Power Rating: It is generally recommended to select a transformer that has a rating equal to at least 20 percent more than your device’s maximum power requirement or consumption. For example, if you have a 1,000-watt microwave oven, you would need to purchase at least a 1,200-watt step-up transformer as not to damage the transformer or the microwave oven.
Voltage Compatibility: You must be sure that the power supply voltage of your local utility matches the voltage requirements indicated for the transformer. Common input-to-output pairs for transformers are: 110V to 220V, 100V to 220V, 208V to 480V (3-phase).
Phase Configuration: You will use one-phase transformers to power residential and commercial grade appliances and/or motors. Three-phase transformers will only be utilized with industrial grade appliances and/or motors. If you attempt to utilize a one-phase transformer with an appliance and/or motor that is equipped with a three-phase configuration, it will be a costly mistake. Three-phase appliances and/or motors require a three-phase transformer and vice versa.
Safety Certification: Always check to see if a transformer has been tested and certified by UL, CE or other international organizations. Various features such as thermal overload protection, short circuit protection and also a grounded plug reduce your chances of fire or electric shock.
Wiring and Installation: Small transformers typically have a plug and play design while three-phase transformers are usually wired by an electrician. Be sure to verify whether the transformer has clear instructions for wiring as a step up transformer, or if you will need to hire an electrician to complete the wiring.
FAQs
What is a step up transformer used for?
A step up transformer is used to raise the voltage of an ac power supply to match the required output of equipment designed for higher voltage. Use as step up transformers are commonly used in travelling (while travelling abroad), as well as with appliances that were manufactured outside the USA, also as supplying power for industrial machinery that requires a higher voltage than is provided by the power grid (local rated voltage).
What happens when I plug a step up transformer in to a 230V outlet?
By plugging a step up transformer into a standard 230V outlet, it will convert the lower voltage electrical input to the higher voltage required for whatever you’re using that step up transformer to provide. This is necessary because every country has different power distribution systems (different voltage levels). Many electrical devices are manufactured to only operate at specific voltages; if using an electrical device manufactured for one voltage (e.g. for the USA @ 120 Volts) on another voltage (e.g. @ 230 Volts), damage to the equipment’s internal workings will occur.
What is the purpose of using a step-up transformer?
The purpose of a step-up transformer is to help safely and efficiently provide the use of the higher voltage devices. Summary –
